AGC – STAINLESS TIE-BAR PLATE AND FRAME HEAT EXCHANGER
“BUILDING THE BEST, SERVICING THE REST”
Please consult with an R-Cap representative to properly size the correct Heat Exchanger unit for your application.
Model AR56-SH Frame
High Pressure 200 PSIG (13.6 Bar) design
Polished to #4 finish
All eight (8) ports supplied for future application
Available in Low leg AR56-S version
2-1/2″ and 4″ Terminal dividers available
Heavy Wall Ports to resist cracks
Parts interchangable with your existing R56-SH/200 frames
Exceeds current 3A specifications
Two Plate Styles to choose from
Model AR56-S Frame
High Pressure 150 PSIG (10.2 Bar) design
Polished to #4 finish
Available in high leg AR56-SH version
2-1/2″ and 4″ Terminal dividers available
Heavy Wall Ports to resist cracks
Parts interchangable with your existing R56-S frames
Exceeds current 3A specifications
Two plate styles to choose from
Optional Features Include: Removable stainless steel or other alloy inserts available
Model PRO3-SH Frame
High Pressure 150 PSIG (10.2 Bar) design
Polished to #4 finish
2-1/2″ Terminal dividers available
Heavy Wall Ports to resist cracks
Parts interchangable with your existing SR350-S frames
Exceeds current 3A specifications
Model PRO2-SH Frame
High Pressure 150 PSIG (10.2 Bar) design
Polished to #4 finish
all eight (8) port supplied for future applications
heavy duty cladded frame polished to #4 finish
Exceeds 3A specifications
Made In the USA
Model 300-S Frame
High Pressure 150 PSIG (10.2 Bar) design
Polished to #4 finish
all eight (8) port supplied for future applications
heavy duty cladded frame polished to #4 finish
